Ventoxx Harmony Smart
Code: VX01
Related products
Product detailed description
The Ventoxx Harmony Smart local heat recovery unit is a quiet and economical decentralized heat recovery unit with an efficiency of up to 94% and an air flow rate of up to 50 m³/h with Wi-Fi connectivity. It provides fresh, filtered air without heat loss or condensation all year round.
Wi-Fi connection
The Ventoxx Harmony Smart recovery unit is equipped with an integrated ESP32-C3 Wi-Fi module, which allows wireless control of the unit via the Smart Life mobile app or other compatible smart home platforms. The module operates in the 2.4 GHz band (802.11 b/g/n) and also supports voice assistants. Via Wi-Fi, you can set operating modes, fan speed, time programs, and monitor the status of the device in real time. The unit can be paired with other Harmony Smart devices for synchronized operation (master-slave). Wi-Fi control also allows remote access, automation based on sensors (CO₂, humidity, temperature) and easy integration into a smart home.
Cover
Ventoxx Harmony Smart has a compact and elegant design suitable for installation in perimeter walls. The front panel is designed to allow airflow and can be easily closed when not in use. It is made of durable plastic and is available in versions for standard and concealed installation.
Fans
The Ventoxx Harmony Smart heat recovery unit is equipped with a reversible axial fan from renowned manufacturer EBM-Papst, which ensures efficient air supply and exhaust at a low noise level of 22–30 dB.
Motor
The highly efficient and economical motor with low power consumption (1.5–4.7 W) guarantees a long service life and reliable operation.
Recuperation
The Austrian-made ceramic heat exchanger with up to 94% efficiency has a hexagonal structure for maximum heat transfer and long-term durability. The cyclic reverse mode allows the supply air to be heated even in winter without additional heating.
Filter
The washable G3 class filter captures dust and impurities before they enter the exchanger and fan, extending the service life of the components and maintaining high indoor air quality.
Electrical connection
Power supply 230 V, can be controlled by remote control (included) or via a Wi-Fi module and the Smart Life mobile app.
Control
11 operating modes, 3 fan speeds, option to pair multiple units for synchronized operation (master-slave). The Wi-Fi version can be programmed and automated based on CO₂, humidity, and temperature sensors.
Noise
Noise level 22–30 dB at a distance of 1 m, with optional Ventoxx Star silencer reducing noise by up to 30%, also suitable for bedrooms.
Installation
Horizontal installation in a wall opening with a diameter of 160–180 mm and an outward angle of 1–3°. Available air ducts 50 cm and 75 cm, can be shortened to 32 cm or extended up to 1.5 m.
Accessories
Optional Ventoxx Star noise silencer, Ventoxx Twist wall controller, metal or plastic outer cover, mounting kits for different wall types.
Instructions
Regular cleaning of filters and exchanger every 3 months, replacement of filters every 2 years. Installation and connection must be carried out by a qualified electrician.
Warning
Before installation, check the suitability of the location and observe the recommended distances from the ceiling, doors and other units.
Additional parameters
| Category: | Ventoxx Harmony - decentralized heat recovery units |
|---|---|
| Warranty: | 2 years |
| Weight: | 7 kg |
| Maximum temperature [°C]: | 50 |
| Duct diameter [mm]: | 150 |
| thermal efficiency [%]: | 74–94 |
| Airflow [m3/h]: | 17–50 |
| Sound level [dB(A)]: | 22–30 |
| Input power [W]: | 1,5–4,7 |
-
