Soler & Palau SILENT DUAL 300

Product detailed description

The S&P SILENT DUAL 300 smart bathroom fan with humidity and motion sensor allows for autonomous speed control. During controlled ventilation, it adjusts its performance to the conditions of the surrounding environment, which it senses using integrated sensors (motion and humidity) without the need for user intervention. The S&P SILENT DUAL 300 bathroom fan can be installed in a wall or ceiling in a horizontal or vertical position.

Fan housing

The housing is made of ABS and is white in color. The discharge is rearward, and the diameter of the discharge nozzle is 99 mm. The housing is designed for wall or ceiling mounting. The fan includes a removable non-return damper. Air is extracted through the center and around the perimeter of the front panel. Airflow is similar to standard panels, but the aerodynamic design of the dual concept allows for higher fan pressure.

Impeller

The impeller is axial and made of impact-resistant plastic.

Fan motor

Maintenance-free AC motor meeting the requirements for precise ventilation with the highest energy efficiency class and low noise parameters. The motor and impeller assembly is mounted on silent blocks. The motor is equipped with a thermal fuse, maximum operating temperature 40 °C, IP45 protection.

Terminal block

The terminal block is accessible after removing the front grille on the fan housing. Easy connection with 2 wires (L, N).

Speed control

The fan allows for autonomous speed control. During controlled ventilation, it adjusts its performance to the conditions of the surrounding environment, which it senses using built-in sensors (motion and humidity) without the need for operator intervention.

Installation

The fan is installed on a wall or in a suspended ceiling, in either a horizontal or vertical position. The Silent Dual bathroom fan is designed for use in short ventilation ducts (max. length 3 m) with low pressure loss or for ventilation through an exterior wall.
