Systemair RVK 200E2-L sileo
Code: SA247019Product detailed description
The Systemair RVK 200E2-L sileo centrifugal duct fan is equipped with an impeller with backward-curved blades and an external rotor motor. The Systemair RVK 200E2-L sileo fan for circular ducts is made of glass-fiber-reinforced PP plastic. The circular duct fan Systemair RVK 200E2-L sileo can be used in humid environments thanks to the high tightness of its housing and the terminal box’s IP44 protection rating.
The speed of the Systemair RVK 200E2-L sileo fan can be continuously adjusted using a thyristor or a 5-step transformer. The motor is protected against overheating by integrated thermal switches with automatic restart. The fans are supplied with a mounting bracket to facilitate installation.
- centrifugal fan
- the fan housing is made of plastic (polyamide)
- adjustable speed
- built-in thermal contacts in accordance with EN 60335-2-80
- can be installed in any position
- reliable, maintenance-free
- the RVK fan includes a mounting bracket
Additional parameters
| Category: | Systemair RVK – plastic centrifugal fans for circular ducts |
|---|---|
| Warranty: | 2 years |
| Weight: | 3.9 kg |
| Voltage [V]: | 230 |
| IP protection: | IP44 |
| Maximum temperature [°C]: | 70 |
| RPM [min-1]: | 2638 |
| Current [A]: | 0,7 |
| Duct diameter [mm]: | 200 |
| Airflow rates [m3/h]: | 1073 |
| Input power [W]: | 164 |
| Typ motoru: | AC |
| Otáčky [min-1]: | 2638 |
| Příkon [W]: | 164 |
| Průtok [m3/h]: | 1073 |
| Akustický tlak [dB(A)]: | |
| Proud [A]: | 0,7 |
