Systemair RVK 100E2 sileo
Code: SA283445Product detailed description
The Systemair RVK 100E2 sileo duct-mounted centrifugal fan is equipped with an impeller with backward-curved blades and an external rotor motor. The Systemair RVK 100E2 sileo fan for circular ducts is made of glass-fiber-reinforced PP plastic. The circular duct fan Systemair RVK 100E2 sileo can be used in humid environments thanks to the high tightness of its housing and the IP44 protection rating of its terminal box.
The speed of the Systemair RVK 100E2 sileo fan can be continuously adjusted using a thyristor or a 5-step transformer. The motor is protected against overheating by integrated thermal switches with automatic restart. The fans are supplied with a mounting bracket to facilitate installation.
- centrifugal fan
- the fan housing is made of plastic (polyamide)
- adjustable speed
- built-in thermal contacts in accordance with EN 60335-2-80
- can be installed in any position
- reliable, maintenance-free
- the RVK fan includes a mounting bracket
Additional parameters
| Category: | Systemair RVK – plastic centrifugal fans for circular ducts |
|---|---|
| Warranty: | 2 years |
| Weight: | 1.8 kg |
| EAN: | 4251599124448 |
| Voltage [V]: | 230 |
| IP protection: | IP44 |
| Maximum temperature [°C]: | 70 |
| RPM [min-1]: | 2482 |
| Current [A]: | 0,171 |
| Duct diameter [mm]: | 100 |
| Airflow rates [m3/h]: | 184 |
| Input power [W]: | 29 |
| Typ motoru: | AC |
| Noise level [dB(A)]: | 34 |
| Otáčky [min-1]: | 2482 |
| Příkon [W]: | 29 |
| Průtok [m3/h]: | 184 |
| Akustický tlak [dB(A)]: | 34 |
| Proud [A]: | 0,171 |
