O.Erre FLAT-e 100
Code: OE0026000
Product detailed description
The O.Erre FLAT-e 100 bathroom fan is a compact radial fan designed for built-in (recessed) installation in plasterboard. It offers two speeds, quiet operation, and an economical motor with a long service life. IPX5 protection.
Cabinet
The O.Erre FLAT-e 100 fan has a robust plastic ABB built-in cabinet designed for wall mounting. Thanks to its compact dimensions and low profile, it does not disturb the appearance of the interior and at the same time provides a long service life even in environments with higher humidity.
Fans
The O.Erre FLAT-e 100 model is equipped with a radial fan with backward-curved blades. This type of fan achieves higher efficiency than axial fans and is suitable for air extraction even over longer distances through ducts.
Motor
The O.Erre FLAT-e 100 fan is powered by a modern BLDC motor with low consumption and a long service life. The motor is mounted in ball bearings, which allow it to operate in any position. Overheating protection ensures safe and reliable operation.
Filter
The O.Erre FLAT-e 100 fan includes a washable filter. It is easily accessible, and regular cleaning extends the life of the device and maintains stable performance.
Electrical connection
The O.Erre FLAT-e 100 model is connected via a terminal block and has an IPX5 rating, making it suitable for use in damp areas. Double insulation ensures safe operation without the need for grounding.
Control
The O.Erre FLAT-e 100 fan has two operating speeds.
Noise
The O.Erre FLAT-e 100 fan is very quiet, with a noise level of around 36 dB(A). This makes it suitable for use in areas where quiet operation is required, such as bedrooms or living rooms.
Installation
The O.Erre FLAT-e 100 unit is designed for surface installation on a wall or ceiling with connection to ducts of 80–100 mm. Thanks to its radial design, it is also suitable for longer and more complex exhaust routes.
Accessories
The O.Erre FLAT-e 100 fan can be purchased with a backflow damper, an outdoor cover with rain protection, or an insect screen. Designer covers are also available.
Instructions
When operating the O.Erre FLAT-e 100 fan, it is necessary to clean the filter regularly and check the airflow in the ducts. Proper maintenance ensures reliable performance and quiet operation throughout the fan's service life.
Additional parameters
| Category: | O.Erre FLAT-e - bathroom fans for surface mounting |
|---|---|
| Warranty: | 2 years |
| Weight: | 1.2 kg |
| Voltage [V]: | 230 |
| Duct diameter [mm]: | 80 |
| Power input [W]: | 9/6 |
| Air flow [m3/h]: | 100/80 |
| Temperature [°C]: | -20 to +45 |
| Pressure [Pa]: | 310/210 |
| Sound level [dB(A)]: | 36/32 |
-
O.Erre FLAT-e IN 100 - prohlášení o shodě (43.6 kB)
-
O.Erre FLAT-e 100 - katalogový list (120 kB)
-
O.Erre FLAT-e 100 - manual (5.5 MB)
